EV CHARGING GUIDE

As we move forward from internal combustion engines to electric vehicles, there are many new words, phrases and acronyms for everyone to learn and understand. There are also a very large range of accessories used to charge electric vehicles, below is a introduction that will help you with getting to know the new technology.

EV LANGUAGE

  • EV - Electric Vehicle

  • BEV - Battery Powered Electric Vehicle

  • PEV - Plug-in Electric Vehicle

  • PHEV - Plug-in Hybrid Electric Vehicle

  • ICE - Internal Combustion Engine eg: petrol or diesel

  • EVSE - Electric Vehicle Supply Equipment

  • J1772 - Type 1 Plug, charging usually at 16amp or 32amp, Single Phase

  • IEC62196 - Type 2 Plug, charging usually at 16 or 32amp Single or 3 Phase

  • CHAdeMO - DC Charging Plug used for Fast Charging

  • Slow Charge - Usually 10amp or 16amp (3.6kW) charging

  • Fast Charging - Direct Current (DC) Charging 50kW or above

  • kW - Kilowatt, a unit for measuring power

  • kWh - Kilowatt hour, a unit for measuring energy

AC EV CHARGING PLUGS

Type 1 EV Plug.jpg

TYPE 1

Also known as: J1772, SAE J1772

This plug is used for single phase charging.

240V AC up to 32amp 7.6kW.

It is used as the standard plug type for Japan and North America



Type 2 EV Plug.jpg

TYPE 2

Also known as: IEC 62196, Mennekes

This plug is used for single and 3 phase charging.

230V AC up to 32amp 7.6kW, Single Phase.

415V AC up to 32amp 22kW, 3 Phase.

It is used as the standard plug type in Europe and has become the standard type of plug used in Australia

DC EV CHARGING PLUGS

Chademo EV Plug.jpg

CHAdeMO

Abbreviated from CHArge de MOve

This plug is used for DC rapid charging only. It is used by Japanese car manufactures



CCS DC EV Charging Plug

CCS Combo

Combined Charging System also called Combo Coupler

This plug is a combination of the type 2 plug with 2 extra contacts for DC rapid charging.

TYPES OF EV CHARGERS

Level 1

The level 1 charger is small and portable, so you can plug it into commonly found power point either at home or at the workplace. The power outlet you wish to plug into must be protected by a residual current device (RCD, safety switch) for protection against electric shock in fault conditions. These are designed to be used as a backup charger and not really designed for everyday use.

Level 2

Charging is supplied via a dedicated plug hard wired back to a switchboard using specific cable capable of carrying higher currents (Amps) and voltages, charging your vehicle in a shorter time than level 1 charging. By using this type of charger it will give you more kilometres per hour of charge which increase the usability of your vehicle and saves you time in waiting for the battery to charge. the level 2 chargers cost more to purchase and have installed, but the advantages make it a worthwhile investment.

Level 3

Fast charging from dedicated DC supply equipment. These are not what you would install in domestic situation due to the cost of the supply equipment and the demand on the electrical supply to the property. They are most suited for side of road service centres and fleet charging where there is a high turnover of vehicles charging or charging time is critical to business operation.

AC vs DC  EV CHARGING

AC vs DC EV Charging.jpg

Difference Between AC and DC  EV Charging

AC charging is achieved via a portable or hardwired EV charger that delivers an alternating current of between 3.6 - 22kW to the vehicle onboard battery management system. This slows the rate of charge as it needs to convert the AC power to DC power. Battery electrical energy is stored in a DC state.

DC charging is from public or semi-public chargers delivering between 23 - 175kW of DC power directly to the vehicle battery.

The DC power bypasses the vehicle onboard inverter making for a much quicker charge time. DC voltages range between 500 - 900VDC, which also impacts charging times. Not all electric vehicles can accept a high voltage with all EV's stopping fast DC charging at 80% and reverting to a slower charge rate.

CHARGING TIMES

Charging times will vary from vehicle to vehicle due to contributing factors such as, the size of the vehicle's on-board charger and the size of the vehicle's battery to be charged. The kW level you select will have an effect on your charging times.

Level 1, 3.7kW AC portable charger.



Level 2, 7kW - 22kW AC

Level 3, 24kW - 175 DC

Kilowatts
Voltage AC/DC
Amperage
Phases
Time 60kW/h Battery
7.2 kW
AC
32 amps
1
8 hrs
3.7 kw
AC
16 amps
1
16 hrs
11 kW
AC
16 amps
3
6 hrs
175 kW
DC
310 amps
3
23 min
24 kW
DC
40 amps
3
2.6 hrs
50 kW
DC
80 amps
3
80 min
22 kW
AC
32 amps
3
3 hrs
Charge times are estimates only.

CHARGING COST

One of the most important factors when purchasing a new vehicle is the running costs. The great news is the running costs for electric vehicles is significantly lower than petrol/diesel vehicles in fuel and servicing costs.



This is how to work out your costs for fuelling your vehicle.

You first need to find out what you pay per kWh for your electricity, you will find this on your electricity bill, likely to be about $0.24/kWh. Now you need to look at the battery size of the electric vehicle you intend to charge. For this example, we will choose the Jaguar I-Pace with a battery size of 90kWh and a range of 470km.



The cost to charge a Jaguar I-Pace is 0.24 x 90 = $21.60



From this equation we can work out the cost per km by dividing the charging cost of $21.60 by the range of 470km, 21.60 / 470 = $0.0459 per km.

0.0459 x 100 = $4.59 per 100km.

You can use this example for any electric vehicle to find out your charging and per kilometre travel cost.
